Belden 6200FE Equal: 16 AWG Shielded Security Cable
Security integrators and low-voltage contractors sourcing a Belden 6200FE Equal need a verified construction match, not a general substitute. Windy City Wire's 441320BR is a 16 AWG, 2-conductor shielded cable built to the same electrical and physical profile, offered as a USA-made, plenum-rated alternative for security and access control circuits.
Why Search for a Belden 6200FE Equivalent
Security and access control cable runs carry more than low-level signal. Card readers, alarm panels, intercoms, and commercial audio circuits all depend on a stable, shielded 2-conductor 16 AWG cable to resist interference and maintain consistent performance over long runs. When a specification calls for a Belden 6200FE Equal, procurement teams and specifiers are really looking for a cable with the same construction and electrical characteristics: 16 AWG bare copper conductors, a foil shield with drain wire, a plenum-rated jacket, and a 300V rating.
That's the sourcing problem a verified Belden 6200FE Equivalent solves. Rather than accepting a general-purpose shielded cable and hoping it performs the same way, buyers can confirm a construction that matches point for point, then source it domestically.
441320BR Spec-for-Spec Verification
The 441320BR is built as a 16 AWG, 2-conductor bare copper, shielded plenum cable, UL Listed and rated Type CMP. Compared directly against the Belden 6200FE, the constructions line up closely across the specifications that matter most to procurement and design teams.
Both cables use 16 AWG stranded bare copper conductors with a black/red color code. Both use a low-smoke PVC jacket and PVC-based conductor insulation, and both carry a white jacket at a nominal diameter within a few thousandths of an inch of each other (441320BR at .184", 6200FE at 0.188"). Shielding is comparable as well: the 441320BR uses an aluminum mylar shield with a 22 AWG, 7 strand tinned copper drain wire, while the Belden construction uses an aluminum/polyester foil shield with a 24 AWG solid tinned copper drain wire.
Electrically, the two constructions are closely matched. The 441320BR carries a nominal capacitance of 76 pF/ft. Both cables share a 0°C to 75°C temperature range, a 300V rating, and a cable weight of 31 lbs per 1000 ft. The 441320BR is also specified with a nominal impedance of 25 Ohms, while the Belden 6200FE datasheet does not publish an impedance value.
The 441320BR also carries markings and certifications relevant to a security cable specification: UL Listed C(UL)US CMP, RoHS compliant, and Made in the USA, with flame rating approved for plenum use without conduit per the NFPA 262 flame test and compliance with NEC Article 800.
One area worth reviewing during a side-by-side comparison is impedance. The 441320BR is specified with a nominal impedance of 25 Ohms, while the Belden 6200FE datasheet does not publish an impedance value. When evaluating a Belden 6200FE Equal, reviewing the complete specifications for both cables helps confirm the construction and electrical characteristics required for the intended application.
Understanding Plenum-Rated Security and Access Control Cables
A CMP, or plenum, rating means a cable has been tested and listed for use in air-handling spaces without requiring conduit. NFPA 262 governs that flame and smoke testing, and NEC Article 800 sets the code requirements that apply to communications circuits, including many security and access control cable runs. When a specification calls for a plenum-rated security and access control cable, it's addressing a real code requirement tied to where that cable physically runs, not just a preference for higher-grade materials.
For integrators and specifiers, this matters at the documentation stage as much as the physical installation. A cable substitution that doesn't carry a verified plenum listing can create a compliance gap on a project, even if the cable performs adequately in day-to-day use. Confirming that a Belden 6200FE Equal carries the same CMP listing and the same NFPA 262 and NEC Article 800 compliance keeps the documentation trail intact.
Where Shielded Security Access Control Cables Are Specified
Shielded 2-conductor 16 AWG cable shows up across a range of commercial and industrial security applications, generally wherever a low-level signal needs protection from electrical noise.
Access control and card reader circuits commonly call for a shielded pair to maintain reliable communication between readers, controllers, and door hardware, particularly in buildings with significant electrical infrastructure nearby.
Alarm and intrusion monitoring systems rely on stable, shielded runs between sensors, panels, and monitoring equipment, where interference can translate directly into false signals or missed events.
Intercom and commercial audio circuits are another primary application for this cable construction, which is why a Belden 6200FE Equivalent is often specified for both security and commercial audio installations rather than security-only applications.
Across all three applications, the shielded 16 AWG 2-conductor construction plays the same role: protecting a relatively low-level signal from the noise generated by surrounding building infrastructure while meeting the plenum requirements common in commercial construction.
Sourcing the 441320BR
For integrators, contractors, and specifiers confirming a Belden 6200FE Equal, the 441320BR offers a spec-matched, USA-made alternative built to the same 16 AWG, 2 conductor shielded, plenum-rated construction. Full cable specifications and part number details are available through the product page above, and the Security & Access Control Resource Center offers additional detail on shielded security and access control cable options. For sample requests or spec sheet confirmation, our team is available to support sourcing decisions directly.
